EXIT/EM/LED Exit & Emergency Light

Features

  • Remote capable unit without lamp heads when specified with NH option
  • Remote capable option available
  • Provides 90 minutes of emergency operation
  • Ultra-bright, energy-efficient, long-life LEDs
  • Adjustable heads provide optimal center-to-center spacing
  • High-performance reflector and plastic lens for optimal light distribution
  • Fully automatic solid-state two rate charger recharges battery in 24 hours
  • Charge rate/power β€œON” LED indicator light and push-to-test switch for mandated code compliance testing
  • Unique design allows double face conversion in the field
  • Removable directional indicators
  • Self-diagnostic option performs monthly, biannual and annual tests to ensure reliable operation and meet electrical and life safety codes
  • Optional polycarbonate shield and wireguard provide added protection
  • Salida faceplate option
  • Optional high lumen heads

Tools

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Specifications

Housing

Injection-molded, engineering-grade, 5VA flame retardant, high-impact resistant, thermoplastic.

Lamp Heads

Chrome-plated metallized reflector and plastic lens.

Electrical

Dual 120/277 voltage standard. 9.6V Long life, maintenance- free, rechargeable NiCd battery. 1 watt (8 LEDs x 0.125W) per head. 3-4W remote capacity when specified with RC option. 6W remote capacity when specified with NH option.

Mounting

Mounting canopy for top or end installation. Universal knockout pattern on back plate for wall mount.

Listings

• UL 924 standard as an emergency/exit light suitable for dry or damp locations (0°C to 40°C).
• Meets NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
• Certified to CEC under Title 20 Regulations.

Warranty

5-year limited warranty.

Accessories

Polycarbonate Shield

Wireguard

Wireguard

Housing Colors

Industry-Standard White

Black
